The GATmatic TWC1600 is a heavy-duty truck tire changer engineered for high-performance commercial applications. It accommodates rim diameters from 14" to 26" and tire diameters up to 63", including off-road, agricultural, and super single tires. Featuring hydraulically operated spreader jaws and a joystick-controlled portable unit, it ensures safe, efficient operation. Its durable, single-piece frame and aluminum-alloy air cylinders withstand rigorous use, making it ideal for demanding workshops.
Features
Ergonomic Portable Control Unit
The TWC1600 features a user-friendly, portable control unit with intuitive joystick controls. This design allows operators to position themselves optimally, ensuring precise and safe monitoring of the tire-changing process.
Robust Spindle, Chuck, and Mount/Demount Head
Engineered for durability, the TWC1600's spindle, chuck, and mount/demount head assembly smoothly rotate, raise, and lower through simple operator commands. This ensures efficient handling of heavy-duty tires.
Swift Setup Mechanism
The machine's quick-positioning system allows for rapid locking of the mount/demount arm, minimizing downtime and enhancing productivity in busy workshop environments.
Heavy-Duty Construction
Built to withstand rigorous use, the TWC1600 boasts a single-piece frame for superior rigidity, aluminum-alloy air cylinders, and a rugged welded steel body. These features contribute to its longevity and reliability.
Hydraulic Spreader Jaws
Equipped with hydraulically operated spreader-type jaws, the TWC1600 ensures secure clamping of virtually all rims and off-road style wheels, enhancing safety and efficiency during operation.
Massive Chuck Spindle
The machine's substantial chuck spindle is designed to handle the heaviest loads, providing stability and precision during the tire-changing process.
Gentle Handling of Sensitive Wheels
The TWC1600 heavy duty truck tire changing machine is engineered to be gentle on over-the-road and tubeless tires mounted on aluminum wheels, minimizing the risk of damage during the tire-changing process.
Specifications
Model
TWC1600
Rim Diameter
14" - 26"
Max Wheel Width
800mm
Max Wheel Diameter
1600mm
Max Wheel Weight
500Kg
Gearbox Motor
1.5KW 220V/380V-3PH
Draulic Pump Motor
1.5KW 220V/380V-3PH
Operating Pressure
0 - 130MPa
Packing
2030*1600*940mm
Net Weight
670Kg
Our Factory
GATmatic was founded in 2013. Our factory covers over 9,000 square meters, including an R&D center, multiple production lines, a quality inspection center, and a modern warehouse. Thanks to our factory’s advanced manufacturing equipment, such as the latest digital control cutting machines, CNC punches, bending machines, and automatic welding machines, we have a strong production capacity.
Package
To avoid irresistible damage during transportation, GATmatic offers excellent packaging methods. In addition, it is also very convenient to load and unload with pallets.
Material: Heavy-duty wooden crate with reinforced corners and waterproof plastic wrapping.
Inner Protection: Insert High-density foam to protect fragile components.
Package Information: Product name, weight (kg), dimensions (L×W×H), and serial number.
Transport method: Choose the better transportation way according to situation: Air freight (for urgent orders) or sea freight (full-container load recommended).
